Hi everyone, does anyone have a can xml file for the Vectra C? I created mine for the 3.2 petrol. I still don’t have a few things, like fuel level, battery charging, or check engine. I can also share my file; it already has a lot of stuff in it and it works.
2 Likes
Please share the file. I will review and put to next release of RealDash.
1 Like
Dash data 3- launch contol flashing
Dash data 5,6- parking sensors front and rear
Dash data 10- P position
Dash data 11- shiftbox position but it shows Numbers instead of PRND. Shifts 1,2,3,4,5 ok
Dash data 19- rear bulbs not working
Dash data 20- rear Windows lock
The rest is described.
Battery voltage, coolant level, oil level, heater motor level i must testing.
Dash data 1,2 i dont remember
my mistake for not describing it, next week I will check it carefully and send an updated file
I still have the fuel level but it is not in this file
Fuel min max
255 07 AE 01 04 04 00 82 00
255 07 AE 01 04 04 00 28 00
Offset 6 lenght 1
VectraC.xml (6.4 KB)
1 Like
I use with Vgate Vlinker MS
Thank you for the file. I will put this to next release of RealDash. We can update it easily later if needed.
2 Likes
I found more data
Id145 offset 2 Startbit 0 - oil pressure indicator light
Id145 offset 1 Startbit 7 - abs indicator light
Id 108 offset 0 Startbit 1 - battery indicator
Could you share your updated XML file?
How can I assign, for example, dash data 1 to my own name so that it displays in realdash options?
